Hnub Ci Vaj Huam Sib Luag Lub Mounting Bracket



Hnub Ci Vaj Huam Sib Luag Lub Mounting Bracket adjustable kaum sab xis ntawm 25 txog 90 degrees, uas tuaj yeem txhim kho kev ua tau zoo ntawm koj lub hnub ci vaj huam sib luag. Los ntawm kev kho lub kaum sab xis ntawm koj lub hnub ci vaj huam sib luag kom lawv ntsib lub hnub ncaj qha, es tsis txhob dag, koj tuaj yeem ua kom muaj txiaj ntsig ntau txog 25 feem pua. Qhov kev hloov kho no tshwj xeeb tshaj yog muaj txiaj ntsig thaum lub caij ntuj no thaum tshav ntuj tsis txaus.

Peb cov racking yog qhov zoo tagnrho rau cov hnub ci vaj huam sib luag txog li 150 watts thiab tuaj yeem ua raws li cov hnub ci vaj huam sib luag mus txog qhov siab tshaj plaws ntawm kwv yees li 700 hli. Qhov ntev ntawm lub hnub ci vaj huam sib luag tsis txwv, vim tias cov mounts tuaj yeem sib cais raws li qhov sib txawv.

Cov mounts ntau yam no tsis txwv rau ib daim ntawv thov; lawv yog cov zoo tagnrho rau mounting hnub ci vaj huam sib luag ntawm lub ru tsev ntawm lub tsev, los tsev, thiab chaw nres tsheb, nrog rau lwm yam tiaj tus. Lawv kuj haum rau hauv av-mounting solar panels.

Kev txiav txim siab lub kaum sab xis zoo tshaj plaws rau koj lub hnub ci vaj huam sib luag yog qhov yooj yim: rho tawm 15 degrees ntawm lub ntiaj teb latitude ntawm koj qhov chaw. Piv txwv li, yog tias koj nyob ntawm 52 degrees sab qaum teb latitude, qhov kev suav yuav yog 52 - 15=37 degrees. Hauv qhov no, lub hnub ci vaj huam sib luag tig rau sab qab teb (nyob rau sab qaum teb hemisphere) thiab qaij 37 degrees ntawm lub hnub yuav tsim lub zog zoo tshaj plaws.

Technical Parameters

Qhov chaw nruab	Qhib av thiab lub ru tsev tiaj tus
Vaj huam sib luag	Hnub ci vaj huam sib luag rau txhua qhov loj me
Vaj huam sib luag kev taw qhia	Vertical lossis toj roob hauv pes
Ru Tsev Clearance	Customized
Kev xav	Customized
Cua load	Mus txog 130 mph (60m / s)
Daus load	Mus txog 30psf (1.4KN / m2)
Khoom siv	Aluminium alloy thiab stainless hlau 304
Warranty	10 xyoo ntawm cov khoom

4 x Tsau L-Brackets

2 x Tilt L-Brackets

6 x M8 Plastic Knob Screws

6 x M8 Wing Nuts

4 x M6 x 16mm Hex Cap Bolts

4 x M6 Split Lock Washers

8 x M6 Flat Washers

4 x M6 Hexagonal Ceev

6 x m8 yuv

6 x M8 Spring Washers

10 x 1¼ hauv Self-Drilling Cap Screws

6 x Plastic Retaining Rings

Qhia kom meej
