Adjustable Tilt Ru Hnub Ci Mounting System

Tilt-in module yuav muab tso rau hauv lub thij tawm extruded ntawm txhua hom ntawm qhov chaw, los ntawm qhov chaw thiab loj lag luam, txoj cai los ntawm kev tso dej ua ntu thiab tuaj yeem siab ua ke nrog lub clamp los txo lub sijhawm thiab tus nqi ntawm kev txhim kho. Tus qauv yuav raug kho lossis kho raws li 10-15 degree, 15-30 degree thiab 30-60 degree raws li koj xav tau.

Xa kev nug

Hauj lwm lawm

2018 Adjustable Tilt System, qaij ceg, Adjustable Tilt System

Yam khoom	Kev piav qhia	Ntev Length
WAD-FL	AD Pem Pem Hauv Ntej
WAD-RL10 / / 15	AD Tsheb Sab Ceg 10 / 15deg	240 ~ 360 hli
WAD-RL15 / 13	AD Tsheb Ciav Hlau 15 / 30deg	340 ~ 680 hli
WAD-RL30 / 60	AD Tawm Ruam 30 / 60deg	700 ~ 1200 hli

braemac qaij duab

Hnub Ci-Hlau-Ru-Mounting-Systems-Adjustable-Tilt-1

Cov txiaj ntsig

1.Easy Installation.
Lub Wanhos hnub ci nruab nrab thiab D-modules tau zoo heev ua kom yooj yim rau lub installation ntawm PV modules.The System yuav ntsia nrog ib tus Hexagon Key thiab txheem cov khoom siv cuab yeej. Pre-assembled thiab pre-cut txheej txheem yuav heev tiv thaiv corrosion thiab txuag koj lub sij hawm installation thiab cov nqi zog.

2.Qhov Nyuaj Siab.
Wanhos hnub ci mounting lawv muaj mounting accessories tsim rau kev siv ntawm yuav luag txhua lub ru tsev thiab hauv av nrog zoo compatibility.Designed raws li ib tug universal racking system, framed modules los ntawm tag nrho cov nrov manufacturers yuav siv tau.

3. Ua Siab Tshaj.
Tsis tas siv qhov chaw txiav, qhov kev siv ntawm peb txoj kev tsheb ciav hlau txuas mus tso cai rau lub kaw lus nrog lub ntsuas millimeter.

4. Sij Hawm Lifespan:
Tag nrho cov khoom ua los ntawm kev ua zoo ntawm extruded aluminium, C-steel thiab stainless hlau.Tus siab corrosion kuj lav tau qhov siab tshaj plaws tau lifespan thiab tseem recyclable kuj.

5. Ntsuas Durability:
Wanhos Hnub ci muab ib qho guarantee ntawm 10 xyoo ntawm lub durability ntawm tag nrho cov khoom siv.

Specification

lnstall Site	Tsis tshua muaj qhov profile ntawm lub tshav dav hlau qhib
Tilt Angle	10deg-60deg
Lub Tsev Dlhos	Mus txog 20m
Max Cua Zog	Mus txog 60m / s
Snow Load	Mus txog1.4KN / m2
cov qauv kawm	AS / NZS 1170 & DIN 1055 & Lwmyam
Cov khoom	Aluminium alloy & Stainless hlau
Xim	Ntuj
Anti-corrosive	Anodized
Warranty	Kaum xyoo warranty
Duratiom	Ntau tshaj 20 xyoo

2018 Adjustable Tilt System, qaij ceg, Adjustable Tilt System

Xiamen Wanhos Hnub Ci Technology Co., Ltd. yog lub koom haum hightech hauv hnub ci PV thaj chaw ua haujlwm hauv hnub ci PV khoom nrog kev siv tshuab thiab cov kev pab zoo heev. Wanhos Cov neeg sab nrauv ua lawv tus kheej mus tshawb fawb, tsim, tsim khoom thiab muag qhov kev yees, kev ntseeg siab thiab cov nuj nqi hluav taws xob ua haujlwm PVAR mounting system. Raws li ib yam ntawm cov khoom loj tshaj plaws PV solar khoom exporter hauv Suav teb, cov khoom pioneering tau raug kho hauv ntau tshaj 100 lub teb chaws thiab cov cheeb tsam txij li nws tau tsim.

Kev Tswj Tswvyim

Wanhos Solar Hnub Tuaj Lub Teeb Nruab Hnub Tuaj Yeem Lub Tswv Yim Txhim Kho Lub Tswv Yim Txhawb Kev Kawm Txuj Ci Rau Txhua Tus Txheem thiab tom qab muab kev pab.

2018 Adjustable Tilt System, qaij ceg, Adjustable Tilt System

Xav paub ntxiv. rau peb tsim thiab cim

• Koj cov pv qhov luaj li cas? ___mm Ntev ntev x___ hli Dav x__mm Thickness
• Koj muaj pes tsawg pawg vaj huam sib luag? _______Nos.
• Dab tsi yog qhov laj thawj nraub qaum? ____degree
• Dab tsi yog qhov koj npaj pv thaiv kev ruaj ntseg? ________Nos. nyob rau hauv ib tug kab
• Cov huab cua nyob li cas, xws li tshuab cua thiab cua txias?
___ m / s siab ceev cua thiab cua hlob ____ KN / m2.
