Cov lus qhia Hnub ci Fotovoltaica Sistema Intergrated hom av ntsia hlau mounting qhib teb

UB-Av Mounting System muaj feem xyuam rau PV qhov system ntawm qhov chaw qhib. Qhov kev ruaj ntseg thiab kev ruaj ntseg ntawm txoj kab ke no yog nrog cov qauv khoom siv thiab kev tsim kho. Rau qhov sib txawv ntawm lub hauv paus ntsiab lus, xws li kev ua vaj tse nrog pre-faus bolt, ncaj nraim faus thiab hauv av ntsia hlau, thesystem yuav muab kho rau nruab. Cov ntaub ntawv siv muaj xws li galvanized hlau thiab anodized txhuas, nrog zoo tiv thaiv corrosion tsim rau sab nraum zoov siv.

Xa kev nug

Hauj lwm lawm

UB Gound Cov Ntsia Hlau

Cov txiaj ntsig

1.Easy Installation.
Lub Wanhos hnub ci nruab nrab thiab D-modules tau zoo heev ua kom yooj yim rau lub installation ntawm PV modules.The System yuav ntsia nrog ib tus Hexagon Key thiab txheem cov khoom siv cuab yeej. Pre-assembled thiab pre-cut txheej txheem yuav heev tiv thaiv corrosion thiab txuag koj lub sij hawm installation thiab cov nqi zog.

2.Qhov Nyuaj Siab.
Wanhos hnub ci mounting lawv muaj mounting accessories tsim rau kev siv ntawm yuav luag txhua lub ru tsev thiab hauv av nrog zoo compatibility.Designed raws li ib tug universal racking system, framed modules los ntawm tag nrho cov nrov manufacturers yuav siv tau.

3. Ua Siab Tshaj.
Tsis tas siv qhov chaw txiav, qhov kev siv ntawm peb txoj kev tsheb ciav hlau txuas mus tso cai rau lub kaw lus nrog lub ntsuas millimeter.

4. Sij Hawm Lifespan:
Tag nrho cov khoom ua los ntawm kev ua zoo ntawm extruded aluminium, C-steel thiab stainless hlau.Tus siab corrosion kuj lav tau qhov siab tshaj plaws tau lifespan thiab tseem recyclable kuj.

5. Ntsuas Durability:
Wanhos Hnub ci muab ib qho guarantee ntawm 10 xyoo ntawm lub durability ntawm tag nrho cov khoom siv.

Specification

lnstall Site	Qhib teb
Tilt Angle	10deg-60deg
Lub Tsev Dlhos	Mus txog 20m
Max Cua Zog	Mus txog 60m / s
Snow Load	Mus txog1.4KN / m2
cov qauv kawm	AS / NZS 1170 & DIN 1055 & Lwmyam
Cov khoom	Aluminium alloy & Stainless hlau
Xim	Ntuj
Anti-corrosive	Anodized
Warranty	Kaum xyoo warranty
Duratiom	Ntau tshaj 20 xyoo

Cov lus qhia Hnub ci Fotovoltaica Sistema Intergrated hom av ntsia hlau mounting qhib teb

Xiamen Wanhos Hnub Ci Technology Co., Ltd. yog lub koom haum hightech hauv hnub ci PV thaj chaw ua haujlwm hauv hnub ci PV khoom nrog kev siv tshuab thiab cov kev pab zoo heev. Wanhos Cov neeg sab nrauv ua lawv tus kheej mus tshawb fawb, tsim, tsim khoom thiab muag qhov kev yees, kev ntseeg siab thiab cov nuj nqi hluav taws xob ua haujlwm PVAR mounting system. Raws li ib yam ntawm cov khoom loj tshaj plaws PV solar khoom exporter hauv Suav teb, cov khoom pioneering tau raug kho hauv ntau tshaj 100 lub teb chaws thiab cov cheeb tsam txij li nws tau tsim.

Kev Tswj Tswvyim

Wanhos Solar Hnub Tuaj Lub Teeb Nruab Hnub Tuaj Yeem Lub Tswv Yim Txhim Kho Lub Tswv Yim Txhawb Kev Kawm Txuj Ci Rau Txhua Tus Txheem thiab tom qab muab kev pab.

Cov lus qhia Hnub ci Fotovoltaica Sistema Intergrated hom av ntsia hlau mounting qhib teb

Cov lus qhia Hnub ci Fotovoltaica Sistema Intergrated hom av ntsia hlau mounting qhib teb _21

Xav paub ntxiv. rau peb tsim thiab cim

Dab tsi yog koj qhov teeb meem pv pav? ___mm Ntev ntev x___ hli Dav x__mm Thickness
Pes tsawg lub vaj huam sib luag yog koj mus rau pem roob? _______Nos.
Dab tsi yog qhov qaij kaum? ____degree
Dab tsi yog koj npaj pv assmebly block? ________Nos. nyob rau hauv ib tug kab

Yuav ua li cas yog huab cua muaj, xws li cua ceev thiab daus load?
___ m / s siab ceev cua thiab cua hlob ____ KN / m2.

Dab tsi yog qhov nyob hauv av ( min qhov siab ntawm theem hauv qab ntu hauv av)?

Koj puas nyiam xaiv ua vaj tse los sis hauv pem teb?
